Design and manufacture of the microwave receiver block of X-band phase array radar

17 views

Authors

  • Nguyen Van Hanh (Corresponding Author) Institute of Radar, Academy of Military Science and Technology
  • Dinh Van Truong Institute of Radar, Academy of Military Science and Technology
  • Vo Van Phuc Institute of Radar, Academy of Military Science and Technology
  • Vo Xung Ha Institute of Radar, Academy of Military Science and Technology
  • Tran Thi Tram Institute of Radar, Academy of Military Science and Technology
  • Pham Khac Lanh Institute of Radar, Academy of Military Science and Technology

DOI:

https://doi.org/10.54939/1859-1043.j.mst.103.2025.40-46

Abstract

The article introduces a method designing and manufacturing a microwave receiver for an X-band phased array radar station on a purpose-built vessel. The design method uses new generation components, based on survey results, functional analysis, and calculation of parameters of the original block that directly affect the formation of the block's function. The microwave receiver block works according to the principle of super-external deviation, mixing frequency twice; its task is to filter and convert microwave pulses into intermediate frequency pulses 2 to the intermediate frequency amplifier.

References

[1]. Nguyễn Thị Ngọc Minh, Lê Ngọc Uyên, Nguyễn Văn Hạnh, "Cải tiến và bán dẫn hoá tuyến thu cao tần đài ra đa -37", Tạp chí Nghiên cứu KHKT & CNQS số 22, tr. 165-171, (2008), (in Vietnamese).

[2]. Nguyễn Thị Ngọc Minh, Nguyễn Văn Hạnh, Trần Mạnh Quý, Trần Thị Trâm, "Một số giải pháp kỹ thuật áp dụng trong thiết kế chế tạo máy thu đa kênh của đài ra đa Cộng hưởng-VN", Tạp chí Nghiên cứu KH & CNQS- Tuyển tập các Báo cáo Khoa học Hội nghị KH Ra đa năm 2011, tr. 153-161, (2011), (in Vietnamese).

[3]. “A 16-element phased-array receiver with beam scanning for advanced automotive radars”, IEEE Transactions on Microwave Theory and Techniques 62 (11):2823-2832, (2014). DOI: https://doi.org/10.1109/TMTT.2014.2354134

[4]. Merrill L.Skolnik, “Chapter 6: Radar receivers”, Radar Handbook, Third Edition, The McGraw-Hill Companies, (2008).

[5]. Peng Yan, Eero Mọki-Esko, Mikko Valkama, and Markku Renfors, "Receiver architectures", Department of Communications Engineering, Tampere University of Technology, Finland, (2010).

[6]. Ioannis Kassotakis, “Modern radar techniques for air surveillance & defense”, Journal of Computations & Modelling, vol.4, no.1, 2014, 189-205 ISSN: 1792-7625 (print), 1792-8850 (online) Scienpress Ltd, (2014).

[7]. Rahul Sadhu, “Design and implementation of modern X band Up/Down converter”, IEEE Xplore, (2022). DOI: https://doi.org/10.1109/ICONAT53423.2022.9726008

[8]. Joseph A. Bruder, “Principles of modern radar, chapter 11 radar receivers”, p. 391–416, (2024).

Downloads

Published

26-05-2025

How to Cite

[1]
T. H. Nguyen Van, Dinh Van Truong, Vo Van Phuc, Vo Xung Ha, Tran Thi Tram, and Pham Khac Lanh, “Design and manufacture of the microwave receiver block of X-band phase array radar ”, JMST, vol. 103, no. 103, pp. 40–46, May 2025.

Issue

Vol. 103 (2025)

Section

Electronics & Automation
